Yongyi Vertical Pumps
Yongyi vertical pumps covers many models, such as single-stage, double case, submersible, semi-submersible, slurry and solid handling and sump. They all have the cerficication of either ISO, ASME or API. Our verticasl pumps not only provide excellent wear life properties, but they are an industry standard for integrated pump design. Numerous sizes, hydraulics and material combinations are particularly well suited for use in mining, metallurgy, power, coal, chemicals, building materials and other industries.
Structure
Product Show
Parameter
| Model | rotate speed n=2950r/min | rotate speed n=1475r/min |
| Flow (m3/h) | Head (m) | ρ=1 | ρ=1.35 | Flow (m3/h) | Head
(m) | ρ=1 | ρ=1.35 |
| Motor power
(KW) | Motor power
(KW) |
| ZAL25-200 | 7.5-11.5 | 28-49 | 2.2-5.5 | 3-7.5 | 4-5.8 | 6.5-12 | 0.75-1.1 | 0.75-1.1 |
| ZAL25-250 | 10.8-12.5 | 46-78 | 5.5-11 | 7.5-15 | 5.4-6.3 | 11.5-19.5 | 1.1-1.5 | 1.5-2.2 |
| ZAL25-315 | 15.3-20 | 74-130 | 15-30 | 22-37 | 7.6-10 | 18.5-32 | 2.2-3 | 2.2-4 |
| ZAL40-160 | 20-28 | 16-33 | 2.2-5.5 | 3-7.5 | 9.5-14 | 4.5-8 | 0.75-1.1 | 0.75-1.1 |
| ZAL40-200 | 18-29 | 20-53 | 4-11 | 5.5-15 | 9.5-14.5 | 7-13 | 1.1-1.5 | 1.1-2.2 |
| ZAL40-250 | 21-32 | 47-78 | 7.5-18.5 | 11-22 | 10.5-16 | 11-19.5 | 1.1-3 | 1.5-4 |
| ZAL40-315 | 29-42 | 61-115 | 15-37 | 22-45 | 15-21 | 15-29 | 3-5.5 | 4-7.5 |
| ZAL50-160 | 31-50 | 17-34 | 3-11 | 4-15 | 16.5-25 | 4-8.4 | 0.75-1.5 | 1.1-2.2 |
| ZAL50-200 | 43-62 | 28-82 | 7.5-18.5 | 11-22 | 22-31 | 7-13 | 1.1-3 | 1.5-3 |
| ZAL50-250 | 50-70 | 45-82 | 15-30 | 18.5-37 | 26-35 | 11-20 | 2.2-4 | 3-5.5 |
| ZAL50-315 | 57-87 | 57-115 | 22-55 | 30-75 | 30-44 | 14-28 | 3-11 | 4-11 |
| ZAL50-400 | 60-82 | 102-194 | 45-110 | 75-160 | 30-41 | 25-48 | 7.5-15 | 11-22 |
| ZAL80-160 | 66-94 | 17-32 | 5.5-15 | 7.5-18.5 | 34-47 | 4-8 | 1.1-2.2 | 1.1-3 |
| ZAL80-200 | 70-103 | 30-54 | 11-30 | 15-37 | 36-51 | 7.5-12.5 | 1.5-4 | 2.2-5.5 |
| ZAL80-250 | 87-127 | 45-82 | 22-45 | 30-75 | 46-64 | 11-20 | 3-7.5 | 4-11 |
| ZAL40-315 | 90-141 | 74-127 | 37-90 | 45-132 | 45-70 | 18-33 | 5.5-15 | 7.5-18.5 |
| ZAL80-400 | 116-171 | 95-187 | 75-160 | 90-220 | 53-85 | 25-46 | 11-22 | 15-30 |
| ZAL100-160 | 110-162 | 12-29 | 7.5-22 | 11-30 | 55-81 | 3-7.2 | 1.1-3 | 1.5-4 |
| ZAL100-200 | 135-193 | 26-50 | 18.5-45 | 30-55 | 70-95 | 6-12.5 | 3-5.5 | 3-7.5 |
| ZAL100-250 | 170-230 | 44-79 | 37-75 | 45-90 | 90-115 | 10-20 | 5.5-11 | 7.5-15 |
| ZAL100-315 | 170-250 | 71-126 | 75-132 | 75-200 | 86-125 | 17.5-31 | 11-18.5 | 11-30 |
| ZAL100-400 | 224-300 | 105-194 | 110-250 | 160-355 | 115-150 | 26-48 | 15-37 | 22-45 |
| ZAL150-250 | 310-190 | 40-74 | 55-110 | 75-160 | 155-195 | 10-18.5 | 11-15 | 11-22 |
| ZAL150-315 | 310-442 | 68-125 | 90-250 | 132-355 | 150-220 | 17-32.5 | 15-30 | 18.5-45 |
| ZAL150-400 | 400-520 | 113-502 | 200-400 | 280-500 | 200-260 | 28-51 | 30-55 | 37-75 |
| ZAL150-500 | | | | | 208-300 | 45-77 | 45-110 | 75-132 |
| ZAL150-630 | | | | | 220-360 | 60-115 | 75-200 | 110-250 |
| ZAL200-250 | 470-610 | 32-72 | 75-160 | 90-220 | 240-305 | 8-17.5 | 11-22 | 15-30 |
| ZAL200-315 | 480-710 | 65-122 | 132-355 | 185-450 | 350-350 | 15-30 | 18.5-45 | 22-55 |
| ZAL200-500 | | | | | 330-495 | 48-84 | 75-185 | 90-220 |
| ZAL200-560 | | | | | 350-540 | 62-105 | 110-250 | 132-355 |
| ZAL200-630 | | | | | 372-580 | 75-132 | 132-315 | 185-450 |
| ZAL250-315 | | | | | 424-545 | 13-27 | 30-55 | 37-75 |
| ZAL250-400 | | | | | 500-660 | 24-49 | 53-132 | 75-160 |
| ZAL250-500 | | | | | 630-800 | 42-82 | 110-280 | 160-400 |
| ZAL250-560 | | | | | 665-860 | 57-106 | 160-400 | 250-560 |
| ZAL300-400 | | | | | 780-1050 | 26-48 | 90-200 | 132-280 |
| ZAL300-500 | | | | | 870-1240 | 42-78 | 160-450 | 250-560 |
| ZAL300-560 | | | | | 950-1340 | 56-104 | 280-560 | 400-800 |
| ZAL300-630 | | | | | 950-1450 | 75-132 | 355-1000 | 500-1400 |
| ZAL300-500 | | | | | 1300-1870 | 38-74 | 220-630 | 315-1000 |
| ZAL300-560 | | | | | 1500-2040 | 54-98 | 355-900 | 500-1250 |
Package
Application
1. Daily Chemicals:Facial Foam, Hair Gel, Hair Dyes, Toothpaste, Shampoo, Shoe Polish, Cosmestics etc.
2. Pharmacy:Nutrition Liquid, Chinese Traditional Patent Medicine, Medicine Grease, Biological Products etc.
3. Chemical Industry:Fat, Dissolvent, Resin, Paint, Pigment, Oil Agent etc.
4. Other Industry:Contruction Industry, Plastic Industry, Textile Industry, Coal Floatation Agent etc.
